BE0940 Beryllium Foil, Be Foil

Catalog No. BE0940
Size Customized
CAS Number 7440-41-7
Purity 98.5%
Chemical Formula Be
Shape Round, Rectangle and Customized
Color Steel Gray
Density 1.85 g/cm3
Melting Point 1560K
Thickness 0.02mm-0.1mm
Condition Vacuum Tight

Beryllium Foil (Be Foil) is on sale at Stanford Advanced Materials (SAM). As a leading supplier of beryllium products across the world, SAM also offers customized shapes and component ratios of beryllium products upon your request.

Related product: Beryllium Sheet, Beryllium wire.

Beryllium Foil Description

Beryllium (Be) is a brittle, steel-gray alkaline earth metal. Beryllium foil is strong, lightweight, and has a modulus of elasticity 50% greater than steel. It has non-magnetic properties and has higher specific heat than any metal. Beryllium foil retains excellent properties at elevated and cryogenic temperatures, making this fascinating metal an ideal thermal conductor. Because of its low density and high thermal conductivity, beryllium has many applications in the aerospace and military industries. Beryllium is also transparent to X-rays and other forms of ionizing radiation, making it a great material for X-ray windows. It is frequently used as a material in acoustic applications for its damping properties and high stiffness-to-weight ratio.

Beryllium is relatively transparent to X-rays and other forms of ionizing radiation. Therefore, it is the most common window material for X-ray equipment and components of particle physics experiments. The beryllium foil could be as thin as 0.0008 inches and 100% tested for vacuum-tight. The foils are supplied cut to shapes such as discs, rectangles, and other custom shapes.

beryllium-foils beryllium-foils



Beryllium Foil Specifications

Thickness: 0.02mm-0.1mm
Width: ≤25mm
Length: ≤50mm
If you require beryllium in thicknesses greater than those shown here, see Beryllium Sheet.

Item No. ME04-98
Chemical Component
Be Fe Al Si BeO Be2C Mg Mn
Value >98.5% <0.115% <0.0068% <0.0058% <1.00% <0.021% <0.0021% <0.005%

Vacuum-Tight
No detectable leakage - Tested by a sensitivity of 1x10-9 atm-cc/sec helium mass spectrometer leak detector.

Surface condition
Uniform in quality and condition, clean, sound, and free from foreign materials, or internal and external imperfections 0.45μm Ra or better surface finish.

Available shapes and dimensions:

Shape

Thickness/mm

Diameter/mm

Width/mm

Length/mm

Round

0.02-0.05

≤50

N/A

N/A

0.05-0.1

≤100

N/A

N/A

0.1-0.5

≤100

N/A

N/A

0.5-1.5

≤100

N/A

N/A

Rectangle

0.02-0.05

N/A

≤50

≤50

0.05-0.1

N/A

≤100

≤100

0.1-0.5

N/A

≤100

≤150

0.5-1.5

N/A

≤100

≤200



Tolerance of Round Sheet/Foil:

Diameter/mm

Tolerance/mm

Thickness/mm

Tolerance/mm

≤50

+0/-0.2

0.02-0.05

+/-0.005

≤100

+0/-0.3

≥0.05-0.1

+/-0.01

≤100

+0/-0.3

≥0.1-0.2

+/-0.02

≤100

+0/-0.3

≥0.2-0.5

+/-0.03

≤150

+0/-0.4

≥0.5-1.0

+/-0.05

≤150

+0/-0.4

≥1.0-1.5

+/-0.1



Tolerance of Rectangle Sheet/Foil:

Thickness/mm

Tolerance/mm

Width/mm

Tolerance/mm

Length/mm

Tolerance/mm

0.02-0.05

+/-0.005

≤50

+0/-0.2

≤50

+0/-0.2

≥0.05-0.1

+/-0.01

≤100

+0/-0.3

≤100

+0/-0.3

≥0.1-0.2

+/-0.02

≤100

+0/-0.3

≤150

+0/-0.4

≥0.2-0.5

+/-0.03

≤100

+0/-0.3

≤150

+0/-0.4

≥0.5-1.0

+/-0.05

≤100

+0/-0.3

≤200

+0/-0.45

≥1.0-1.5

+/-0.1

≤100

+0/-0.3

≤200

+0/-0.45



Beryllium Foil Applications

Used in the medical industry for imaging, diagnostics, and laser applications due to its strength and stability.
  - Beryllium is used in imaging equipment for Homeland Security.
  - Beryllium foil is used in high-resolution medical radiography.
  - Beryllium is used in analytical equipment for blood, HIV, and other diseases.

Used in communications to manufacturing telecommunication infrastructure and telephones.
  - Beryllium materials have low electrical resistance and high thermal conductivity to support the convergence and miniaturization of compact devices.

Used for aerospace and military applications due to its lightweight properties, low density, and high thermal conductivity.
  - Lightweight beryllium components are frequently applied to electronics and military systems requiring precise operation under extreme conditions.
  - Pure beryllium used in military fighter jets requiring speed and maneuverability.
  - Beryllium components enhance surveillance and targeting systems in military helicopters.
  - Military communications use copper-beryllium alloys in-network tubes, rotors, and switches due to its high strength and electrical/thermal conductive properties.

Miscellaneous uses include:
  - Used as a component in particle physics experiments.
  - Used as a material in acoustic applications for its damping properties.
  - Beryllium is used to manufacture x-ray tubes and detectors required to monitor the flow of water, oil, and gas during good extraction.

beryllium window beryllium window



Beryllium Foil Packaging

Our beryllium foil is carefully handled to minimize damage during storage and transportation and to preserve the quality of our product in its original condition.

Inner Package outer package
