All about Molybdenum Wire and EDM Wire Cutting

In the world of precision machining, every thousandth of a millimeter matters. And in Electrical Discharge Machining (EDM), where metal is removed using controlled sparks, the type of wire you use plays a major role. One material that’s been quietly revolutionizing the field is molybdenum wire.

Fig. 1 EDM Machining

EDM Wire Cutting Basics

--What's So Special About Wire EDM?

Wire EDM (Electrical Discharge Machining) is a non-contact cutting process that takes away material by means of electrical discharges (sparks). The beauty of this process is that it is able to cut even the hardest metals without the application of physical force. That is, no mechanical stress, no tool wear like traditional cutting, and the ability to achieve very fine tolerances.

In wire EDM, the electrode is a thin metal wire. As the wire sweeps near the workpiece, electrical discharges generate high heat, which vaporizes or melts the material. It's especially used for tool and die production, aerospace parts, and high-precision components.

--EDM Wire Cutting Components

The system includes a wire (usually brass or molybdenum), a dielectric fluid (typically deionized water), a power supply, and a computer-controlled motion system. The choice of wire affects everything — speed, accuracy, cost, etc.

[1]

Fig. 2 EDM Wire Cutting Components

Molybdenum Wire Used in EDM

--So, Why Use Molybdenum Wire?

Molybdenum is a refractory metal known for its very high melting point (~2620°C), high tensile strength, and electrical conductivity. Therefore, it is quite useful for wire EDM.

1. Reusability and Longevity

As opposed to brass, moly wire is recyclable. Moly wire in the majority of Asian-designed EDM machines (DK77 series models, for instance) is cycled and looped over and over — at times hundreds of times before losing its edge. This saves substantially on wire consumption and maintenance over the long term.

2. Clean, Sharp Cuts

Because of its tensile strength and resistance to heat deformation, moly wire keeps its shape. It gives constant tension, which means cleaner cuts and tighter tolerances in hard materials like titanium or tool-hardened tool steel.

3. Faster Cutting with Less Breakage

Molybdenum wire provides the ability for quicker cutting cycles because it can withstand breaking while being subjected to tension and heat. This reliability is especially invaluable for use within the aerospace and electronics industries where precision and lost time are highly valued.

4. Ideal for Thin and Detailed Spaces

When accurate geometries are required, moly wire does not sag and flex, or deflect, so it will perform better in sharp corners and in complex 3D profiles.

[2]

Fig. 3 EDM Wire Cutting Process

--When to Use Molybdenum Wire?

While molybdenum wire has a higher upfront cost per meter than brass, it often proves cheaper in the long run due to its reusability. It’s the wire of choice for:

• Repetitive production runs
• High-hardness materials (carbide, Inconel, tool steels)
• Tight-tolerance work
• Applications in aerospace, defense, medical, and mold/die manufacturing

However, moly wire is not suitable for continuous-feed EDM machines common in many Western shops. It’s used mainly in reciprocating (non-consumable) EDM systems, which support looped wire motion.

--Things to Watch Out For

Like any tool, molybdenum wire has its limits. Keep these in mind:

• Not for Continuous-Feed Machines: Most Western wire EDM setups aren’t compatible.
• Wire Diameter Matters: Common diameters range from 0.10 mm to 0.20 mm. Match the size to your job’s detail and material.
• Tensioning Is Critical: Proper wire tension ensures accurate cuts and prevents wire breakage.
• Reconditioning Needed: Even though moly wire lasts longer, it does wear down eventually. Watch for signs of reduced cutting quality and replace as needed.

--Electrode Materials for EDM Wire Cutting

For more information and technical support, please check Stanford Advanced Materials (SAM).

Frequently Asked Questions

1. Can I use molybdenum wire on any EDM machine?
Not exactly. It’s mainly used in machines designed for looped or reciprocating wire systems, especially in Asian-style EDM setups.

2. Is molybdenum wire more expensive than brass wire?
Yes per meter, but since it’s reusable, the total cost over time is often lower.

3. What types of parts benefit most from molybdenum wire?
Small, complex, or high-precision parts made from hard materials — like dies, molds, or fine components in aerospace and electronics.
