Economic Rapid Heating Microwave Furnace KSL-MW-XX Description
Economic Rapid Heating Microwave Furnace KSL-MW-XX is a horizontal tube furnace equipped with a 3KW programmable AC power source, making it an economical choice for exploring flash-sintering techniques with ceramic materials. This furnace features an 80mm OD alumina tube and a sliding sample fixture that can preheat samples up to 1600°C. The sample holder uses a ceramic screw to press an electric wire against the sample, allowing the passage of electricity from the programmable AC power source, which can be set up to 1500W.
Flash-sintering has emerged as a pivotal technology in materials science research, widely used in the development of solid-state electrolytes, Solid Oxide Fuel Cells (SOFC), and materials with magnetic and thermoelectric properties. This makes the KSL-MW-XX an essential tool for cutting-edge research in these fields.
Economic Rapid Heating Microwave Furnace KSL-MW-XX Specifications
|
Features
|
- Stainless steel casing design for shielding microwave radiation
- SiC foam as heating elements
- Vacuum casting thermal insulation material for better energy saving.
|
|
Microwave
|
- Frequency: 2.45 GHz ±25 MHz
- Output: 600W, 1400W and 1800W
- Microwave leaking: ≤1 mW/cm²
|
|
Basic Parameters
|
- Max. Heating Temp.: 1650℃(<30min), 1600℃(continuous)
- Heating Zone length: 18"
- Constant temperature zone: 6" (150 mm) within +/- 1°C
|
|
Power
|
Type1: 1000W, 110VAC, Single Phase, 50/60Hz
Type2: 1900W, 208-240VAC, Single Phase, 50/60Hz
Type3: 2800W, 208-240VAC, Single phase, 50/60Hz
|
|
Working Temp.
|
Type1: 850℃, K-type Thermocouple
Type2: 1100℃, K-type thermocouple
Type3: 1400℃, S-type thermocouple
|
|
Heating Elements
& Thermal Insulation
|
- SiC foam is employed as a heating element which is a microwave susceptor
- One ZrO2 crucible is included, which is also a microwave susceptor. and inserted inside the SiC disk
- Note: Zirconia crucible is easy to crack during rapid heating, which is consumable
- SiC Graphite crucible is also available.
- The SiC heater is placed inside a fibrous alumina casing as the thermal insulation layer
|
|
Heating Rate
|
- Heating rate: 0 ~50°C / min programmable
RT- 200°C: Max. 25°C /min
200 - 600°C Max. 50°C/min
600 - 1100°C Max. 25ºC/min
- Heating time: 60 minutes Max.
|
|
Net Weight
|
20kg, 30kg
|
|
Dimension
|
Furnace: 520Lx 380Wx 310H (mm); 553(L) x 490 (W) x 343 (H) ( mm)
Controller: 370Lx 310 W x150H (mm)
|
|
Warranty
|
- One-year limited warranty with lifetime support.
- Consumables, including crucibles, heating elements, and heat insulation materials are not covered by the warranty.
- ATTENTION: Any damages caused by the use of corrosive and acidic gasses are not under the coverage of SAM One Year Limited Warranty.
|
|
Certificate
|
- CE Certified
- NRTL or CSA certification is available at extra cost.
|
Economic Rapid Heating Microwave Furnace KSL-MW-XX Applications
- Material Synthesis and Processing: These furnaces are ideal for synthesizing advanced materials, including ceramics, composites, and metallic alloys.
- Sintering of Ceramics: Microwave furnaces are particularly useful in the sintering of ceramic materials.
- Research and Development: Due to their efficient heating and precise temperature control, these furnaces are used extensively in research laboratories for developing new materials and processes.
Economic Rapid Heating Microwave Furnace KSL-MW-XX Packaging
Our Economic Rapid Heating Microwave Furnace KSL-MW-XX is carefully handled during storage and transportation to preserve the quality of our product in its original condition.
