Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Description:
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder is a nickel-based superalloy powder known for its outstanding properties. Produced via gas atomization with argon, this powder demonstrates excellent corrosion and oxidation resistance. It maintains impressive tensile, yield, and creep-rupture properties even at high temperatures up to 700°C (1300°F). The room temperature static properties of components produced using this powder and processed by Powder Bed Fusion-Laser Beam (PBF-LB) are comparable to those of AMS 5662 bar material. These attributes make Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder an excellent choice for demanding applications in aerospace and power generation gas turbines, as well as various other industrial components.
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Specifications:
|
Nominal Chemistry
|
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al
|
|
Nom. Particle Size Distr.(µm)
|
-45 +15
|
|
Morphology
|
Irregular
|
|
Liquidus Temperature (°C)
|
1340
|
|
Solidus Temperature (°C)
|
1260
|
|
Max. Service Temperature (°C)
|
760
|
|
Range of Apparent Density (g/cm3)
|
4.0
|
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Applications:
1. Aerospace Components: Ideal for gas turbine components such as blades, vanes, and combustion chambers due to its high-temperature strength and resistance to oxidation and corrosion.
2. Power Generation: Used in power generation turbines and components where durability and high-temperature performance are critical.
3. Aerospace Airframe Parts: Suitable for certain aerospace airframe components that require a combination of high strength, oxidation resistance, and structural integrity.
4. High-Temperature Industrial Equipment: Applied in industrial equipment and machinery that operate at elevated temperatures and require resistance to thermal degradation and mechanical stress.
5. Engine Components: Effective for various engine components exposed to high temperatures and harsh operating conditions, ensuring long-term performance and reliability.
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder Packing:
Our Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder is carefully handled during storage and transportation to preserve the quality of our product in its original condition.
Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder FAQ:
Q1: What are the key benefits of using Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder?
A1: This powder provides excellent corrosion and oxidation resistance, superior tensile, yield, and creep-rupture properties, and maintains performance at high temperatures up to 700°C (1300°F), making it ideal for demanding aerospace and power generation applications.
Q2: What types of components are suitable for Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder?
A2r: Suitable for aerospace gas turbine components, power generation turbines, certain aerospace airframe parts, high-temperature industrial equipment, and various engine components.
Q3: How do the properties of Ni 18Cr 18Fe 5(NbTa) 3Mo 1Ti 0.6Al Powder compare to AMS 5662 material?
A3: The room temperature static properties of PBF-LB processed and heat-treated material coupons made from this powder are comparable to those of AMS 5662 bar material, offering similar performance in terms of strength and durability.
