PBN0955 PBN Machined Products

Catalog No. PBN0955
Size Thickness: 0.5mm~4mm
Material PBN, Pyrolytic Boron Nitride
Purity 99.99%

Stanford Advanced Materials provide the full range of CVD material, such as pyrolytic graphite, pyrolytic boron nitride, and silicon carbide coated graphite. As PBN and graphite are machinable materials, we could offer custom manufacturing services and deliver all kinds of products.

PBN Machined Products Description

As PBN and graphite are machinable materials, we could offer custom manufacturing services and deliver all kinds of products. These including crucibles, dishes, trays, boats, electrical insulators, coated graphite products, furnace components, heating elements, vaporizing pots, rods, bars, sheets, tubes, and more.



 Compared with normal boron nitride ceramic, pyrolytic boron nitride (PBN) has raw materials with a much higher purity level. PBN sheets, discs, and other pyrolytic boron nitride products are synthesized on the mold by chemical vapor deposition (CVD) process, with BCl3 and NH3.

BCl3 + NH3 àBN +3HCl

Pyrolytic boron nitride advanced ceramics exhibits high resistance to electric but good thermal conductivity. It is a high purity material with no porosity which could be deposit on all kinds of graphite shapes by chemical vapor deposition (CVD). Although Pyrolytic boron nitride could be deposited on various materials, it is usually used on graphite only, since the temperature of this CVD process is extremely high and the atmosphere is corrosive. PBN coated graphite materials significantly enhanced the performance of the surface. Better purity, lower porosity, and roughness. PBN material could also stand high temperatures (2500`C). As the coated products have great performance in high vacuum and high-temperature circumstances, they are ideal for applications in the semiconductor industry.

PBN Machined Products Material Properties

Structure of pyrolytic boron nitride and graphite

Item

value

Unit

lattice constant

a:2.504×10-10     c:6.692×10-10

μ m

density

2.0-2.19

g/cm3

resistivity

3.11×1011

Ω·cm

tensile strength(ab)

153.86

N/mm2

bend strength

c

243.63

N/mm2

ab

197.76

N/mm2

elastic modulus



235690

N/mm2

Thermo conductivity



“a” direction    “c” direction



(200℃)

60                  2.60

W/m·k

(900℃)

43.70             2.80

W/m·k

dielectric strength(at room temperature)

56

KV/mm





Stanford Advanced Materials also provide pyrolytic graphite(PG) products. Click here or send an inquiry for more information.
